BIM Ready models
WE CAN CONVERT THE POINT CLOUD INTO A BIM READY FORMAT, REVIT, AUTOCAD, or CIVIL 3D MODELS
BIM, or building information modelling, is a system that adds information to 3D CAD models, generating 2D plans, sections, and elevations automatically. It is crucial for new construction and renovation projects, with 3D laser scanning being an essential application. BIM sheets can be produced for plans, sections, and elevations, but are not as detailed as typical 2D surveys. Specification is crucial in the BIM environment, and collaboration with clients and key stakeholders is essential for final specification development.
THINGS WE DO TO KEEP AS-BUILT BIM MODEL EASY TO USE:
All families created from the point cloud have a word “SURVEY” as a prefix in their name. This indicates that particular element was created from the point cloud data only.
Our models are positioned with real-world coordinates in mind, but we use a Project Base Point to reposition each building to local coordinates or to match some particular orientation (like from the existing drawings).
All models are created in collaborate mode. We can provide both detached (local) model as well as central model. We can continue to work on received central file and send it back for synchronisation.
All elements or areas that are not possible to recreate from the point cloud are marked up or described as assumed (by project parameters, scope boxes, dedicated set of section views or in any other way suitable for our client).
Special set of filtered views are provided in every model to indicate that certain elements in the model require clients’ attention.
We always take into account the client’s’ requests.
We use the same set of shared project parameters to provide extra survey information within the model.
Project examples – BIM models:
